16-Port 10/100Mbps Switch

Description: The TL-SF1016DS Fast Ethernet Switch provides you with a high-performance, low-cost, easy-to-use, seamless and standard upgrade to improve old network to 1000Mbps network. All 16 ports support auto MDI/MDIX, no need to worry about the cable type, simply plug and play.HARDWARE FEATURESStandards and ProtocolsIEEE 802.3i, IEEE 802.3u, IEEE 802.3xInterface16 10/100Mbps RJ45 Ports (Auto Negotiation/Auto MDI/MDIX)Network Media10Base-T: UTP category 3, 4, 5 cable (maximum 328.1feet)EIA/TIA-568 100Ù STP (maximum 328.1feet)100Base-Tx: UTP category 5, 5e cable (maximum 328.1feet)EIA/TIA-568 100Ù STP (maximum 328.1feet)Fan QuantityFanlessDimensions ( W x D x H )11.6×7.1×1.7 in. (294×180×44 mm)Power Supply100-240VAC, 50/60HzPERFORMANCESwitching Capacity3.2GbpsMAC Address Table8KPacket Forwarding Rate2.38MppsGreen Technology Innovative energy-efficient technology saves power up to 25%Transfer MethodStore-and-ForwardOTHERSCertificationFCC, CE, RoHSPackage Contents:- 16-Port 10/100Mbps Desktop/Rackmount Switch- Power Cord- Installation Guide- Rackmount Kit- Rubber FeetSystem RequirementsMicrosoft® Windows® 98SE, NT, 2000, XP, Vista™, Windows 7 or Windows 8, MAC® OS, NetWare®, UNIX® or Linux.EnvironmentOperating Temperature: 0℃~40℃ (32℉~104℉);Storage Temperature: -40℃~70℃ (-40℉~158℉);Operating Humidity: 10%~90% non-condensingStorage Humidity: 5%~90% non-condensing
